PRODUCT
Prexs Internal Wall Panel is a new generation building material composed of two faces of super durable 4-layer coated steel of Bluescope (Australia) and EPS main core on modern European technology continuous production line. Bonded with tight clamped Z lock, easy to joined together without external adhesive, the surface is smooth or delicately ribbed with flexible length, exactly cut according to design.
- Depth: 50/75/100/125/150mm
- Heat endurance: -10 to 50 Celsius
- Materials imported from: EU and U.S
CONTACT US
DESCRIPTION
With its light weight, component of EPS main core is reinforced 02 ends at the clamping positions with foam core on modern European technology continuous panel production line, tight Z lock mounter, easy to be jointed together without external adhesive agent, the size can be custom made as requested by investors, Prexs Wall Panel is a light material, highly profiling, good bearing and heat resistant that will perfectly replace conventional wall building materials in construction, namely cover walls, external walls of factories, warehouses, etc.
Technical Construction
Prexs Internal Wall Panel is sandwich panel constructed of:
- The core is mainly composed of EPS with 2 edges of clamping positions reinforced with foam core by modern European technology continuous panel production line.
- The solid core with thickness from 50mm, 75mm 100mm;
- Two faces are shielded with super durable steel 4-layers coated by Activate technology of Bluescope Sumo.
- The panels are joined by Zlock + mounting system, tight, free of leakages, drainage of cold temperature to outside, preventing bacteria and mold or pollutants in air from depositing, sponging on.
- Surface of wall panel is smooth or delicately ribbed with exact length customized according to design requirement.
Features of Product
- Insulation, soundproof, colorproof.
- Increase rigidity for walls, ceiling.
- Easy to construct, quickly install.
- Save time of construction, save man power.
- Save frame, truss and purlin.
- High durable, aesthetic, safe for human health.
- More optimal cost than other materials of the same function.
Popular colors of Bluescope Sumo for sandwich panel (*)
(*) In addition to the standard colors above, if you want to choose other colors, please contact Sales Department.
Applications of Prexs Wall Panel - Internal Wall
Factory
Cold storage
Clean room
Store house
Schools
Hospital
Prexs Internal Wall Panels are applied in erection of internal walls, interior partitions, insulation partitions, etc. anti-noise, insulation, high colorproof used to assemble factories for seafood processing, agricultural product processing, food processing, short-term production factories, or temporary shelters, motels, worker accommodation and projects with low investment costs
Prexs Internal Wall Panel are also suitable to the projects on weak ground, where is possible to create light structure, easy to combine with erection at height, reducing gravity of the foundation and structure. Thus, Prexs Internal Wall Panel is used for factories, factories as interior partitions, insulation partitions to replace conventional brick wall and concrete walls.
SECTION
SPECIFICATIONS
Thickness:
50, 75, 100, 125, 150 (mm)
Working width:
1160/1000mm
Maximum length:
6m
Steel brand:
Bluescope Sumo
Standard steel thickness:
0.46mm
Insulation core:
EPS
Weight (/m2) with thickness 100mm
8.2~9.7
REASONS TO CHOOSE THE PRODUCT
Sandwich panel have stable quality, is trusted by hundreds of contractors, used for thousands of projects nationwide
The most diverse range of products in the market with all types: Panel EPS, Panel PU, Panel PIR, Panel rockwool
The leading production line of Europe, Vietnam's largest production capacity of sandwich panel meet schedule for every projects
